| Business Type | Supplier, Trader |
| Country of Origin | India |
| Model | AIES-15-16 & AIES-15-30 |
| Loading Capacity (kg) | 500kg |
| Click to view more | |
Product Details
Lowered Mast Height (mm)
2080 Mm
Fork Lowered Height (mm)
90mm
Overall Length (mm)
1280 Mm
Overall Width (mm)
700 Mm
Turning Radius (mm)
1200
Application
Material Handling
Specifications
| MODEL | AIES-15-16 | AIES-15-30 |
| Loading Capacity (KG) | 1500 | 1500 |
| Loading Center (mm) | 500 | 500 |
| Lifting Height (mm) | 1600 | 3000 |
| Lowered Mast Height (mm) | 2080 | 2080 |
| Overall Height (mm) | 2080 | 3500 |
| Fork Lowered Height (mm) | 90 | 90 |
| Overall Length (mm | 1280 | 1280 |
| Overall Width (mm) | 700 | 700 |
| Fork Dimensions (mm) | 60/140/1070 | 60/140/1070 |
| Distance Between Fork Arms (mm) | 284-660 | 284-660 |
| Turning Radius (mm) | 1200 | 1200 |
| Ground Clearance (mm) | 25 | 25 |
| Lifting Speed (mm/ second) | 9.5 | 9.5 |
| Battery Capacity | 24V120AH | 24V120AH |
| Net Weight (KG) | 370 | 436 |
